PACKAGINGS – EVERYTHING FROM ONE SOURCE

Semi-Automatic Strapping Machines

Strapping & Bundling - fast & safe

The high-performance URM-line (semi-or all-automatic) by tbs-pack is particularly characterized by its user-friendly and robust design. Depending on the model, the strapping process can be triggered either manually (via button or foot switch) or automatically (via sensor). Of course, our URM-systems can be integrated into new or already existing conveyor systems.

Customized frame sizes are available on request.

Fields of application: Securing and bundling of cardboard packagings, magazines, boxes, long and loose products etc.

Technical Details:

  • integrated magnetic tape storage, automatic strap conveyance
  • user-friendly workflow
  • high throughput due to microprocessor control
  • adjustable strap tension (manual / electronic)
  • fast strap changing system (manual / electronic)
  • height-adjustable supporting feet on rolls
  • silent fill head

Strapping Machine: Product Video

Different Models:

URM-205

ModelURM-205
Max. strap width:5-15,5 mm
Connected load (max.):100/110/220/230/240, 50Hz, 1-Phase
Power consumption:0,2 kW
Strap tension:2-55 kg
Machine size (L x B x H):780mm x 550mm x 750mm
Machine weight:63 kg


Features:

  • electric voltage regulation,
  • adjustable cooling time,
  • energy-saving motor (only runs with strap)


URM-206

ModelURM-206
Max. strap width:5-15,5 mm
Connected load (max.):100/110/220/230/240, 50Hz, 1-Phase
Power consumption:0,4 kW
Strap5-55 kg
Machine size (L x W x H):895mm x 565mm x 740mm
Machine weight:100 kg


Features:

  • electric voltage regulation,
  • adjustable cooling time,
  • energy-saving motor (only runs with strap)


Options:

  • adjustable legs,
  • power cut switch




    URM-303

    ModelURM-303
    Max. strap width:5-15,5 mm
    Connected load (max.):100/110/220/230/240, 50Hz, 1-Phase
    Power consumption:0,15 kW
    Strap tension:2-55 kg
    Machine size (L x W x H):780mm x 550mm x 750mm
    Machine weight:50 kg


    Features:

    • electric voltage regulation,
    • adjustable cooling time,
    • energy-saving motor (only runs with strap)


    URM-306

    ModelURM-306
    Max. strap width:5-15,5 mm
    Connected load (max.):100/110/220/230/240, 50Hz, 1-Phase
    Power consumption:0,4 kW
    Strap tension:5-55 kg
    Machine size (L x W x H):895mm x 565mm x 740mm
    Machine weight:110 kg


    Features:

    • electric voltage regulation,
    • adjustable cooling time,
    • energy-saving motor (only runs with strap)

    Option:

    • power cut switch


    * It is not possible to combine all maximum dimensions

    ** The output quantities per minute are averages depending on film type, thickness, product dimension and machine handling

    Convince yourself of our Strapping Machines and make an appointment today with our showroom or with one of our reference customers at +492235 - 47048 - 0 or at info_at_tbs-pack.de.
